Viewtech Programmable Radar Sensor VTR8M

8m Radar Module for VTRIF Radar Interface Kit

More than 5 in stock

SKU: VTR8M Categories: , Brand:


The Viewtech Programmable Radar Sensor VTR8M is a heavy duty radar object detection sensor with 3 detection zones.

It is built of high quality polycarbonate and certified to IP69K ensuring correct operation in all weather conditions.

The sensor comes with an in-cab LED display for driver warning. It uses FMCW (Frequency Modulated Continuous Wave) technology to effectively determine objects behind the vehicle. This ensures  a detection time of under 200ms.

  • Detection Ranges: 5m, 6m and 9m
  • Detection Widths: 3m, 4m and 6.5m
  • Range Accuracy: 0.3m
  • Target Detection Time: Under 200ms
  • Transmitter Frequency: 24.05 ~ 24.20GHz (EU, FCC, KC)
  • Operating Voltage: 12-32VDC
  • Current Draw: 300mA
  • Rugged Rating: IP69K
  • Vibration: 15G
  • Radar and Sensor Dimensions: 108 (L) x 110 (H) x 34 (D)
  • Operating Temperature: –40°C to +85°C
