Description
The product is Industrial 4-Port Gigabit PoE++ 1-Port Gigabit RJ-45 1-Port Gigabit SFP Unmanaged Ethernet Switch.
The switches provide 4*10/100/1000Mbps Ethernet RJ-45 ports, 1*10/100/1000Mbps Ethernet RJ-45 uplink port, 1*1000Mbps SFP uplink port. It meets IEEE 802.3af/at/bt standard. Uplink RJ-45 port supports up to 90W PoE++ power input. All downlink RJ-45 ports support Power-over-Ethernet (PoE++), which can deliver up to 90W power per port.
The switches support the Q-PoE (Quick PoE) technology, which enables PoE power supply immediately upon switch startup without waiting for switch system software control.
The switches support 2 working modes through DIP switch: Default and CCTV. Under CCTV mode, the transmission distance is extended up to 250m, but the rate is limited to 10Mbps. It can be widely used in video security monitoring systems, network projects, etc.
Features
- 4*10/100/1000Base-T RJ-45 (Auto MDI/MDIX) PoE++ ports
- 1*10/100/1000BASE-T RJ-45 (Auto MDI/MDIX)(Supports up to 90W PoE++ power input)
- 1*1000BASE-X SFP
- 1*Relay
- Redundant power supply
- 6kV surge immunity
- Fan-less metal shell design
- IEEE 802.3af/at/bt
