Description
Features
- High quality image with 6MP, 1/2.7″ CMOS sensor
- EasyStar technology ensures high image quality in low illumination environment
- 120 dB true WDR technology enables clear image in strong light scene
- Built-in Mic
- Smart IR, up to 30 m IR distance
Specifications
| Sensor | 1/2.7″, 6.0 megapixel, progressive scan, CMOS |
| Lens | 2.8 mm@F1.6 |
| DORI Distance | Detect 63.0 m | Observe 25.2 m | Recognize 12.6 m | Identify 6.3 m |
| Angle Of View (H) | 112.9° |
| Angle Of View (V) | 59.1° |
| Angle Of View (O) | 121.2° |
| Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 80° | Rotate: 0° ~ 360° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination | Support Easystar: Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >56 dB |
| IR Range | Up to 30 m (98ft) IR range |
| Wavelength | 850 nm |
| IR On/Off Control | Auto/Manual |
| Defog | Digital Defog |
| WDR | 120 dB |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 Code Profile | Baseline profile, Main profile, High profile |
| Frame Rate | Main Stream: 6 MP(3072*2048), Max 25fps; 5.3 M (3072*1728), Max 30fps; 5 MP (2880*1620), Max 25fps; 4 MP (2560*1440), Max 25fps; 3 MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
| Video Bit Rate | 128 Kbps~16 Mbps |
| 9:16 Corridor Mode | Supported |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Image | |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Supported |
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| Dewarping | N/A |
| HLC | Supported |
| BLC | Supported |
| Smart | |
| Behavior Detection | Cross line, intrusion(based on human body detection) motion detection, tampering alarm, audio detection |
| General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, 802.1x, SNMP |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
| Client | EZStation EZView EZLive |
| Web Browser | Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+ |
| Audio | |
| Audio Compression | G.711 |
| Suppression | Supported |
| Sampling Rate | 8KHZ |
| Storage | |
| Edge Storage | Micro SD, up to 256 GB |
| Network Storage | ANR, NAS(NFS) |
| Interface | |
| Network | 10/100 M Base-TX Ethernet |
| Built-in Mic | Supported |
| Certification | |
| Certification | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
| General | |
| Power | DC 12V±25%, PoE (IEEE 802.3af) | Power consumption: Max 6.0 W |
| Dimensions (Ø x H) | Φ110.5 x 94.1 mm |
| Net Weight | 0.42 kg |
| Material | Metal |
| Working Environment | -30 °C ~ 60 °C, Humidity: ≤95% RH (non-condensing) |
| Storage Environment | -30 °C ~ 60 °C, Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 4KV |
| Ingress Protection | IP67 |
| Reset Button | N/A |
