Physical & Power
|
|
Front panel
|
Aluminum
|
|
RAM / ROM
|
2GB / 16GB
|
|
Display
|
7 Inch IPS LCD
|
|
Screen
|
7 Inch capacitive touch screen
|
|
Main Camera
|
2M pixels, automatic lighting
|
|
Auxiliary Camera
|
1M pixels
|
|
Light sensor
|
Support
|
|
Infrared sensor
|
Support
|
|
Wiegand port
|
Support
|
|
RS485 port
|
Support
|
|
RF card reader
|
13.56MHz & 125kHz
|
|
Relays ln/out
|
3/3
|
|
Microphone
|
-32dB
|
|
Speaker
|
8Ω / 2W
|
|
Bluetooth
|
Support
|
|
Ethernet port
|
RJ45, 10/100Mbps adaptive
|
|
|
802.3at Power-over-Ethernet
|
|
IP/IK Level
|
IP65/ IK06
|
|
Installation
|
Flush-mounted & Wall-mounted
|
|
Flush-mounted DIM
|
324x130x60mm
|
|
Wall-mounted DIM
|
324x130x33mm
|
|
Working Humidity
|
10-90%
|
|
Working Temperature
|
-20°C – +55°C
|
|
Storage Temperature
|
-40°C – +70°C
|
|
Audio
|
|
|
SIP v1 (RFC2543), SIP v2 (RFC3261)
|
|
Narrowband audio codec
|
G.711a, G.711μ, G.729
|
|
Broadband audio codec
|
G.722
|
|
DTMF
|
In-band, out-of-band DTMF (RFC2833), SIP Info
|
|
|
Echo Cancellation
|
|
|
Voice Activation Detection
|
|
|
Comfort Noise Generator
|
|
Video
|
|
Sensor
|
1/2.8″, CMOS
|
|
Pixels
|
CIF, QCIF, VGA, 4CIF, 720p, 1080p
|
|
Video codec
|
H.264
|
|
Video resolution
|
up to 1920x1080p
|
|
Max. image transfer rate
|
1080p – 25fps
|
|
Viewing angle
|
105(H)/55°(V)
|
|
|
High intensity IR LEDs for picture lighting during dark hours with internal light sensor
|
|
|
White LEDs for QR code scanning
|
|
|
Compatible to 3rd-party video components,
|
|
Networking and Protocol
|
|
Protocols support
|
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
|
|
Door Entry Feature
|
|
|
Android OS for any 3rd-party software or customization
|
|
|
Relays controlled individually by DTMF tones
|
|
Multi-way Unlock
|
Face, IC/ID Card, PIN and BLE
|
|
|
Camera permanently operational
|
|
|
Auto-night mode with LED illumination
|
|
White balance
|
auto
|
|
Minimum illumination
|
0.1LUX
|
|
Deployment & Maintenance
|
|
|
Auto-Provisioning
|
|
|
Web management portal
|
|
|
Web-based packet dump
|
|
|
Configuration backup / restore
|
|
|
Entry log export
|
|
|
Access table export / import
|
|
|
Firmware upgrade
|
|
|
System logs (include door access logs)
|
|
Application Scenario
|
|
|
Office door phone with on-site or hosted IP-PBX
|
|
|
Remote site entry over Internet
|
|
|
Apartment/flat intercom with door access control
|
|
|
Business information or a welcome experience for guests
|
