Description
The Vertiv™ Liebert® GXE UPS in an online double conversion single phase UPS which offers power protection in an affordable and efficient system with deployment and operation flexibility. The high output power factor (0.9) of the Liebert GXE UPS enables continuous and reliable power to more connected devices, protecting them against many disturbances in the AC mains with the online double conversion technology. It is suitable to provide power protection to the critical equipment for any application.
Specifications
| Power Rating (VA/W) | 2000VA / 1800W |
| Form Factor | Tower |
| Dimensions | 160 x 420 x 245 |
| Weight | 19.4kg |
| Voltage Range Without Battery Operation (230V default, derating applies) | 110 – 290 |
| Voltage Range Without Battery Operation (230V default, 100% load) | 180 – 290 |
| Frequency Range (Hz, Autosnsing) | 40 – 70 |
| Input Connector | IEC60320 C20 |
| Surge Protection (J) | 600 |
| Output Voltage | 220/230 (default) /240 |
| Waveform | Pure Sine Wave |
| Output Overload (AC Mode) | 105% – 110% @ 10 min 111% – 130% @ 30 sec 131 – 150% @ 2 sec > 150% @ inmediate |
| Output Receptacles | 8 x IEC60320 C13 |
| Efficiency (online mode, max.) | 89% |
| Efficiency (ECO mode, max.) | 95% |
| Battery Type | Valve-regulated, non-spillable, lead-acid |
| Recharge Time | <4hr @ 90% |
| Backup Time (100% load, minutes) | 3.2 |
| Backup Time (50% load, minutes) | 9 |
| Compatible with External Battery Cabinets | No |
| Operating Temperature | 0 to 40℃ |
| Relative Humidity (operation, non-condensing) | 5% to 95% |
| Operating Altitude (m), without derating | 2000 |
| Audible Noise (line mode) | <53dBA |
| Compliance | CE, CB Report, UKCA, Morocco, RCM |
| Safety | IEC/EN 62040-1 |
| Surge Immunity | EN 61000-4-5 |
| Transportation | ISTA 2A |
| Environmental | RoHS, REACH, WEEE |
| Slot for optional cards | Yes |
| Communication Port | USB |
| Emergency Power Off (EPO) | Yes |
