Description
Features
- High quality image with 8MP, 1/1.8″CMOS sensor
- 8MP (3840*2160)@ 30(Intelligent off)/25fps; 5.3MP (3072*1728)@ 30/25fps; 3.6MP (2560*1440) @30/25fps; 2MP (1920*1080) @30/25fps; 720P (1280*720), Max 30/25fps
- Ultra 265, H.265, H.264, MJPEG
- Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
- Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
- Intelligent People Flow Counting and Crowd Density Monitoring
- Colorhunter technology ensures 24-hour full-color images
- F1.0 Super aperture
- 120dB true WDR technology enables clear image in strong light scene
- Support 9:16 corridor Mode
- Alarm:1 in/1 out, Audio: 1 in/1 out
- Supports 512 G micro SD card
- IK10 vandal resistant and IP67 protection
Specifications
Camera | |
Max Resolution | 8 MP |
Sensor | 1/1.8″ CMOS |
Min. Illumination | Colour: 0.0005 lux (F1.0, AGC ON) |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 72°, Rotate: 0° ~ 360° |
S/N | >56 dB |
WDR | 120 dB |
Lens | |
Focal Length | 2.8 mm |
Iris Type | Fixed |
Iris | F1.0 |
Field of View (H) | 113.5° |
Field of View (V) | 68.3° |
Field of View (D) | 133.0° |
DORI | |
DORI Distance (Lens) | 2.8 mm |
DORI Distance (Detect) | 63.0 m |
DORI Distance (Observe) | 25.2 m |
DORI Distance (Recognize) | 12.6 m |
DORI Distance (Identify) | 6.3 m |
Illuminator | |
Supplemental Light | Warm light |
Illumination Distance (Warm Light) | 30 m |
Light On/Off Control | Auto/Manual |
Video | |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Frame Rate |
Main Stream: 8 MP (3840*2160), Max 30fps;5.3 MP (3072*1728), Max 30fps; 3.6 MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps |
H.264 Code Profile | Baseline profile, Main profile, High profile |
Video Bit Rate | 128 Kbps to 16 Mbps |
U-code | Support |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Support |
Video Stream | Triple Streams |
Image | |
Smart Illumination | Support |
White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 |
Digital Noise Reduction | 2D/3D DNR |
Flip | Normal, Flip Vertical, Flip Horizontal, 180°, 90°Clockwise, 90°Anti-clockwise |
HLC | Support |
BLC | Support |
Defog | Digital Defog |
Intelligent | |
Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
People Counting | Support People Flow Counting and Crowd Density Monitoring |
Events | |
Basic Detection | Motion Detection, Ultra Motion Detection, Tampering Alarm, Audio Detection |
General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication |
Audio | |
Audio Compression | G.711U, G.711A |
Audio Bitrate | 64 Kbps |
Two-way Audio | Support |
Suppression | Support |
Sampling Rate | 8 kHz |
Storage | |
Edge Storage | Micro SD, up to 512 GB |
Network Storage | ANR, NAS (NFS) |
Network | |
Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH |
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
User/Host | Up to 32 users, 2 user levels: administrator and common user |
Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
Client | UNV-Link, UNV-Link Pro, EZStation |
Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
Interface | |
Audio I/O | 1 Input: impedance 35 kΩ, amplitude 2 V [p-p], 1 Output: impedance 600 Ω, amplitude 2 V [p-p] |
Alarm I/O | 1/1 |
Built-in Mic | Support |
Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
Certification | |
EMC |
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
Safety |
CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection |
IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
General | |
Power | DC 12V±25%, PoE (IEEE 802.3af) |
Power Consumption | Max 11.0 W |
Power Interface | Ø5.5 mm coaxial power plug |
Dimensions | Ø129 x 110 mm (Ø x H) |
Weight | 0.64 kg |
Material | Metal |
Working Environment | -30 ℃ to 60 ℃, Humidity: ≤ 95% RH (non-condensing) |
Storage Environment | -30 ℃ to 60 ℃, Humidity: ≤ 95% RH (non-condensing) |
Surge Protection | 4 KV |
Reset Button | Support |
