XS6RG

Red/Green LED Approach Light

Description

The Viewtech Red/Green Approach Lights are primarily used on mobile and fixed plant to provide a rugged and dependable visual indicator of a machine’s current status. Designed for high-impact communication, these lights use a steady-burn signal to define safe approach conditions for ground staff; for example, a green light indicates the plant is powered on but the hydraulics are disengaged, making it safe to approach, while a red light signals that the plant is active and should not be approached. Built to withstand the vibration and harsh conditions of worksite machinery, they are an essential tool for maintaining clear safety protocols around heavy plant.

Applications

  • Material Handling
  • Skid Steers
  • Diggers
  • Rollers
  • Road Working
  • Industrial Plant

Main Features

  • Red / Green LEDs
  • Only 13mm in thickness.
  • Dual-colour
  • Long lasting LED modules
  • Salt protected
  • Multi-voltage
  • High vibration resistance
  • 3 year NZ/AU Warranty

Included

  • Light Module
  • 3M Sticker
  • Nuts & Bolts
LED Modules 3 × 3 W Cree Red LED
3 × 3 W Cree Green LED
Power 12 – 24 VDC
Dust/Water Rating IP67
Materials Polycarbonate lens,
stainless hardware,
treated alloy housing
Operating Temperature -40 ~ 65 °C
Dimensions 130 × 33 x 13.5 mm
Compliance ECE R65 Single Flash,
ECE R10 SAE,
J595 CLASS1 Double Flash
