Description
Protecting objects of any size
LineSupply offers versatile wired security system coverage for facilities of any size, whether a renovation or a new project. The device provides power to connected Fibra devices and extends the line length to 2,000 meters. LineSupply enables installer to combine up to 10 modules on a single line, boosting a line length for up to 20 kilometers. This flexibility opens numerous possibilities to effectively cover factories, farms, cottage communities, or other large-scale facilities.
Key features
- Output Fibra line length up to 2,000 m
- Additional power supply for the Fibra line
- Remote control and configuration
- Up to 10 modules on the Fibra line
- Protects connected devices from – Short circuit; Overvoltage
- Convenient mounting and cable management when installed into Case
- Up to 2,000 m range of communication with an Ajax hub or a module that extends the Fibra line
- Zero power consumption from the Fibra line
Compatible hubs
- Hub Hybrid (2G)
- Hub Hybrid (4G)
Thoughtful design with safety in mind
Working with a power supply module must be safe, so LineSupply Fibra enclosure is designed to insulate every element exposed to current. It also has special rails, allowing the device to be quickly mounted inside a compatible Case without additional holders. Installers can choose two options for positioning the device with a 180-degree rotation. Passive ventilation protects the module from overheating. With two available enclosure colors, combining LineSupply with any Case is easy.
Record Fibra line length
Typically, the output device’s line can reach 2,000 m. With LineSupply, the total Fibra line length can reach 22 km. An installer just needs to use up to 10 modules one after another on a Fibra line. As a result, the wired Ajax system can cover the territory of a factory, power plant, farm, office, or shopping center with underground parking or any other large facility.
Discover future-proof hardware
- Prevents overheating
- Connects the module to the built-in Case tamper.
- 45 W version has one output line.
- Completely isolates the output lines from the hub power supply.
- Protects against wrong battery poles, short circuit, and overvoltage at the output.
- Help to install the device into Case in one move.
- Informs about module states.
- Informs about connection state of power supply, input and output lines.
